Brand Name : KN
Model Number : Gabion Retaining walls
Certification : ISO CE
Place of Origin : CHINA
MOQ : 100pc
Price : USD 16-20
Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability : 5000m2 per day
Delivery Time : 7-8 days
Packaging Details : pallets Gabion Retaining walls
Surface Treatment : Hot-dipped Galvanized, Galfan Coated
Mesh Size : 60x80mm, 80x100mm, 100x120mm
Wire Diameter : 2.0-4.0mm
Features : Flexible, Durable, Easy to Install
Material : Galvanized Steel Wire
Tie Wire : 2.2mm
Application : Erosion Control, Slope Stabilization, Riverbank Protection
Tensile Strength : 350-500N/mm2
Color : Silver or Green
Selvedge Wire : 3.4mm
Zinc Coating : 240-290g/m2
Size : 2x1x1m, 3x1x1m, 4x1x1m, or customized
Unit Weight : 2.0-4.0kg/m2
Packing : Packed in bundles or on pallets Gabion Retaining walls
Lacing Wire : 2.2mm
galvanized or pvc coated Horizontal Double Twisted Hexagonal Wire Mesh Gabion Retaining walls
Durability:
Galvanized or PVC-coated metal wires are corrosion-resistant. protection wall
Gabion | |
Hole Type | Hexagonal |
Production process | Three twist / Five twist |
Material | GI wire,PVC coated wire,galfan wire |
Wire Diameter | 2.0mm-4.0mm |
Hole Size | 60×80mm,80×100mm,100×120mm,120×150mm |
Gabion Size | 2m×1m×0.5m,2m×1m×1m,3m×1m×0.5m,3m×1m×1m4m×1m×0.5m, 4m×1m×1m,Other sizes can be customized. |
Key Features and Benefits
1. economy. Just put the stone into the cage and seal it. 2. The construction is simple without special technology.
3. It has a strong ability to resist natural damage, corrosion resistance and adverse climate impact.
4. It can withstand large-scale deformation without collapse.
5. The silt between the stone gaps of the cage is conducive to plant production and can be melted into one with the surrounding
natural environment.
6. It has good permeability and can prevent damage caused by hydrostatic force. Conducive to the stability of hillside and beach
7. Save transportation cost, fold it up for transportation and assemble it on the construction site. 8. Good flexibility: no
structural joint, the overall structure has ductility.
9. Corrosion resistance : galvanized materials are not afraid of seawater.
10. Environmental protection materials: cadmium (CD) < 10ppm, lead (PB) < 50ppm,
other harmful substances such as mercury (Hg), hexavalent chromium (Cr6 +), PBB and PBDE are not detected, which fully meet the environmental protection standards of Rosh.
Applications
Our gabion mattresses are widely used in various applications, including:
Erosion Control: Stabilizing soil and preventing erosion in riverbanks, coastal areas, and slopes.
Slope Stabilization: Reinforcing steep slopes and embankments to reduce the risk of landslides and soil instability.
Channel Lining and Bank Protection: Serving as durable linings for channels and culverts, preventing scouring and enhancing hydraulic performance.
Landscaping and Aesthetic Enhancement: Adding texture and visual interest to outdoor spaces while blending harmoniously with natural surroundings.
Manufacturing Excellence
As the largest manufacturer in China, we have state-of-the-art production facilities and advanced technology to ensure the highest quality standards. Our factory is ISO-certified, and we provide SGS test reports to guarantee the reliability and durability of our products. We also adhere to international standards such as ASTM A974 and ASTM A641.
![]() |
Galvanized Or Pvc Coated Gabion Cage Retaining Wall Horizontal Double Twisted Hexagonal Wire Mesh Images |
